Auto Service Shop Lubrication Oil Dispensing System Design Drawing
$18.88
Unit price
$0.00/mg
This lubrication oil dispensing system design drawing presents a professional layout solution developed for quick-service automotive maintenance shops and vehicle service workshops. The design focuses on improving oil management efficiency, workshop organization, and operational reliability through a centralized lubrication distribution system.
The system adopts a centralized oil storage solution consisting of three main pipelines. Each main pipeline is connected to a large-capacity lubrication oil storage tank with an approximate volume of one cubic meter. Each storage unit is dedicated to a specific oil grade, ensuring clear oil separation, simplified inventory management, and stable oil supply during daily maintenance operations.
From the storage area, the three main pipelines extend into the service workshop, where five vehicle maintenance bays are equipped with dispensing points. Each pipeline supplies lubrication oil to five dispensing guns distributed across the workstations, allowing technicians to perform oil-filling operations efficiently without moving oil containers within the workshop.
Each dispensing gun is connected to a 10-meter flexible hose installed on an automatic hose-reel system. During operation, technicians can extend the hose to the required working distance, and after use the hose automatically retracts into the reel. This configuration improves workspace cleanliness, reduces hose wear, and enhances operational safety in the service environment.
This system design drawing provides a practical reference for automotive service shops, quick-maintenance centers, and small vehicle repair facilities planning to implement a structured lubrication oil distribution system. The layout emphasizes reliability, ease of maintenance, and efficient workshop workflow integration.
